Self-operated regulator introduction and installation attention

Self-operated regulator is a new type of regulator.Compared with manual control valve, Self-operated regulator has the advantage of automatic control;Self-operated regulator has the advantage over the electric control valve that it does not require external power.Application practice has proved that in closed water circulation system (such as hot water heating system, air conditioning frozen water system), the correct use of this Self-operated regulator can easily realize the flow distribution of the system;The dynamic balance of the system can be realized.Self-operated regulator can greatly simplify the debugging of the system;Self-operated regulator Can stabilize the working state of the pump.



Self-operated regulator has many advantages, so it is more and more favored by the majority of customers, but to make the product to play a better role, so in the installation, we need to pay attention to the following points.

1, Self-operated regulator in gas or low viscosity liquid medium, usually ZZY self-operated pressure control valve for vertical installation on the horizontal tube, when the position space is not allowed to inverted or inclined.
2, In order to facilitate on-site maintenance and operation, the Self - operated regulator should be left with an appropriate space around.
3. When the medium is clean gas or liquid, the filter before the Self - operated regulator may not be installed.
4. If the pressure control valve is too large in size (DN≥100), there should be a fixed support.
5, the position is really not allowed, bypass valve (manual) can be omitted (we do not recommend).
6, After the Self-operated regulator group according to the needs of the user can be selected check valve, safety valve, etc.
7, Self-operated regulator in steam or high viscosity liquid medium, usually ZZY self-operated pressure control valve is installed upside down on the horizontal tube, the condenser (steam with self-operated) should be higher than the regulator valve actuator and lower than the valve before and after the connection.The use of the front condenser should be filled with cold water, about 3 months after the irrigation.
